Multifunctional Digital Dent Pulling Machine FY-8BX FY-9BX

-: Microprocessor control system optimizes the welding parameters. Due to the adoption of advance digital control technology and user friendly
design, all you have to do is select the welding current corresponding to the workpiece thickness to achieve the best weld quality.
-: Automatic mains voltage monitoring.
-: Welding gun testing function to evaluate the using status of welder more completely. Overheat protection.
-: Suitable for dent pulling of different kinds of car steels such as conventional steel, stainless steel, etc.
-: Various of welding procedures are available such as shrinking,washer,direct-pulling, spot welding, flattening, waveform wire, stud welding,
OT washer, triangle washer, etc .
-: Digital control system with steady power output.

　

Specifications:

FY-9BX

Input Voltage:

Rated Input Power:

Rated Input Current:

Max Output Current:

Output Voltage:

Welding Time Range:

Material Thickness:

Packing Dimensions:

　
Gross Weight:
　
AC200V or 380V 50/60Hz
　

11.5KVA

32A

1800A

1-11V

0-99s

0.8+1.2mm

64×34×33.5cm (Main Machine)

65×18×86cm (Trolley)
　

31kg / 24.5kg

Accessories

Accessories

Quantity

F002 Pulling Hammer with Hook

F003 Dent Pulling Spot Hammer

F006 Wavy Wire

F007 Carbon Rod

F008 Spot Welding Electrode Tip

F009 Carbon Rod Connector

F010 Wavy Wire Electrode Tip

F011 Washer Connector

F014 Claw

F015 Triangle Washer

F016 Stud

F017 ɸ12mm Washer

F017 ɸ10mm Washer

F018 Earth Clamp

F019 Manual Cupule

F030 OT Washer

F033 Wrench

F034 Stud Connector

1 set

1 set

15pcs

3pcs

1pc

1pc

1pc

1pc

1pc

10pcs

30pcs

15pcs

15pcs

1pc

1pc

20pcs

1pc

1pc

　

　

Main Machine

Dimensions:

Package Information:
Metal frame and carton
More Detail:

Optional Quick Puller

Pictures for reference only, please subject to our available products.
